Description
LITTELFUSE - 0298100.ZXEH - Fuse, Automotive, Bolt Down, Time Delay, 100 A, 32 V, 68.58mm x 16.2mm x 10.67mm
- Blow Characteristic: Time Delay
- Fuse Current: 100A
- Voltage Rating V DC: 32V
- Auto Blade Fuse Size: 68.58mm x 16.2mm x 10.67mm
- Product Range: -
- Breaking Capacity Current DC: 2000A
- Colour: Yellow
- Colour Code: Yellow
- External Depth: 19.05mm
- External Length / Height: 10.67mm
- External Width: 68.58mm
- Fuse Breaking Capacity Voltage DC: 32VDC
- Fuse Size Code: MEGA
- Fuse Type Blowing Characteristic: Slo Blo
- I²t Pre-arcing: 31100
- Operating Temperature Max: 125°C
- Operating Temperature Min: -40°C
