LUMBERG - 0322 14 - Circular Connector, 03 Series, Cable Mount Receptacle, 14 Contacts, Solder Socket, Threaded
- Product Range: 03 Series
- Circular Connector Shell Style: Cable Mount Receptacle
- No. of Contacts: 14Contacts
- Circular Contact Type: Solder Socket
- Coupling Style: Threaded
- Connector Body Material: -
- Connector Body Plating: -
- Contact Material: Brass
- Contact Plating: Gold
- SVHC: Lead (15-Jan-2019)
- Cable Diameter Max: 8mm
- Cable Diameter Min: 4mm
- Colour: Nickel
- Conductor Area CSA: 0.25mm²
- Connector Mounting: Cable Mount
- Connector Type: Circular Industrial
- Contact Gender: Socket
- Contact Plating: Gold Plated Contacts
- Contact Termination: Solder
- Contact Termination Type: Solder
- Current Rating: 3A
- External Diameter: 18.5mm
- External Length / Height: 53mm
- Gender: Receptacle
- IP / NEMA Rating: IP68
- Operating Temperature Max: +85°C
- Operating Temperature Min: -40°C
- Proof Voltage: 1V
- Standard: IEC 60130-9
- Thread Size: M16x0,75
- Voltage Rating VAC: 60V
