Description
HARTING - 09 14 001 4651 - USB Connector, USB Type A, Plug, 4 Ways, Cable Mount, Right Angle
- USB Connector Type: USB Type A
- USB Standard: -
- Gender: Plug
- No. of Positions: 4Ways
- Connector Mounting: Cable Mount
- Orientation: Right Angle
- Contact Material: -
- Contact Plating: -
- Product Range: -
- SVHC: No SVHC (15-Jan-2018)
- Approval Category: DIN EN 61984
- Connector Mounting Orientation: Cable
- Connector Type: USB A
- Contact Termination: Screw
- Contact Termination Type: Screw
- Current Rating: 1A
- Degree of Pollution: 3
- Flammability Rating: UL94V-0
- Insulation Resistance: 10Mohm
- Material: Polycarbonate
- No. of Contacts: 4Contacts
- No. of Mating Cycles: 500
- Operating Temperature Max: +125°C
- Operating Temperature Min: -40°C
- Standard: USB 2.0
- Termination Method: Screw
- Voltage Rating VAC: 50V
