Description
MULTICOMP PRO - MCSDC1006-152KU - Power Inductor (SMD), 1.5 mH, 190 mA, Unshielded, MCSDC1006, 10mm x 9.8mm x 5.8mm
- Inductance: 1.5mH
- RMS Current (Irms): 190mA
- Inductor Construction: Unshielded
- Saturation Current (Isat): -
- Product Range: MCSDC1006 Series
- Power Inductor Case: 10mm x 9.8mm x 5.8mm
- DC Resistance Max: 5ohm
- Inductance Tolerance: ± 10%
- SVHC: No SVHC (15-Jan-2019)
- External Depth: 9.8mm
- External Length / Height: 5.8mm
- External Width: 9.8mm
- Lead Spacing: 2.8mm
- No. of Pins: 2Pins
- Q Factor: 31
- Resonant Frequency: 1kHz
- Self Resonant Frequency Min: 1.7MHz
