Description
BOURNS - SDR0604-151KL - Power Inductor (SMD), 150 µH, 400 mA, Unshielded, 540 mA, SDR0604
- Inductance: 150µH
- RMS Current (Irms): 400mA
- Inductor Construction: Unshielded
- Saturation Current (Isat): 540mA
- Product Range: SDR0604 Series
- Power Inductor Case: 5.8mm x 5.8mm x 4.8mm
- DC Resistance Max: 1.1ohm
- Inductance Tolerance: ± 10%
- SVHC: No SVHC (07-Jul-2017)
- External Depth: 5.8mm
- External Length / Height: 4.8mm
- External Width: 5.8mm
- No. of Pins: 2Pins
- Operating Temperature Max: 125°C
- Operating Temperature Min: -40°C
- Q Factor: 20
- Q Test Frequency: 796kHz
- Resonant Frequency: 6MHz
- Self Resonant Frequency Min: 6MHz
- Test Frequency: 0.796MHz
