VISHAY - M70Y104KB25 - Trimpot, Multi Turn, Cermet, Side Adjust, 100 kohm, Through Hole, 20 Turns
- Track Resistance: 100kohm
- No. of Turns: 20Turns
- Potentiometer Mounting: Through Hole
- Product Range: 70Y Series
- Power Rating: 500mW
- Resistance Tolerance: ± 10%
- Temperature Coefficient: ± 100ppm/°C
- Automotive Qualification Standard: -
- MSL: -
- Adjustment Type: Screwdriver Slot
- Approval Category: MIL-R-22097
- Contact Resistance Variation +: 3%
- End Resistance: 2ohm
- External Length / Height: 8mm
- Full Power Rating Temperature: 85°C
- Lead Diameter: 0.8mm
- Operating Temperature Max: 150°C
- Operating Temperature Min: -55°C
- Operating Temperature Range: -55°C to +150°C
- Proof Voltage: 1000V
- Resistance: 100kohm
- Resistor Element Material: Cermet
- Resistor Mounting: Through Hole
- Resistor Terminals: Radial Leaded
- Temperature Coeff. +: 100ppm/°C
- Temperature Coeff. -: 100ppm/°C
- Tolerance +: 10%
- Tolerance -: 10%
- Track Taper: Linear
- Voltage Rating: 400V
- Voltage Rating V DC: 400V
