MOR07WJ0332B09 RES, 3K3, 5%, 7W, AXIAL, METAL OXIDE MULTICOMP PRO

MULTICOMP PROUGS :MOR07WJ0332B09 Code de commande:1357938

Prix:
Prix ​​promotionnel€2,87

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (5456 unité)

Documents et téléchargements

description

MULTICOMP PRO - MOR07WJ0332B09 - Through Hole Resistor, 3.3 kohm, MOR, 7 W, ± 5%, Axial Leaded, 750 V

  • Resistance: 3.3kohm
  • Product Range: MOR Series
  • Power Rating: 7W
  • Resistance Tolerance: ± 5%
  • Resistor Case Style: Axial Leaded
  • Voltage Rating: 750V
  • Resistor Element Material: Metal Oxide
  • Temperature Coefficient: ± 350ppm/°C
  • Automotive Qualification Standard: -
  • SVHC: No SVHC (15-Jan-2019)
  • External Length / Height: 32mm
  • No. of Pins: 2Pins
  • Operating Temperature Max: 155°C
  • Operating Temperature Min: -55°C
  • Operating Temperature Range: -55°C to +155°C
  • Resistor Mounting: Through Hole
  • Temperature Coeff. +: 350ppm/°C
  • Temperature Coeff. -: 350ppm/°C
  • Tolerance +: 5%
  • Tolerance -: 5%
  • Voltage Rating V DC: 750V
