description
VISHAY - RTO50F 82R 5% - Through Hole Resistor, 82 ohm, 50 W, ± 5%, TO-220, 300 V
- Resistance: 82ohm
- Product Range: -
- Power Rating: 50W
- Resistance Tolerance: ± 5%
- Resistor Case Style: TO-220
- Voltage Rating: 300V
- Resistor Element Material: Thick Film
- Temperature Coefficient: ± 150ppm/°C
- Element Limiting Voltage: 300V
- External Depth: 4.5mm
- External Length / Height: 28.7mm
- External Width: 10.1mm
- Full Power Rating Temperature: 25°C
- Lead Length: 13.7mm
- Operating Temperature Max: 155°C
- Operating Temperature Min: -55°C
- Operating Temperature Range: -55°C to +155°C
- Overload Capability: 2 x pr for 5 secs
- Power Rating with Heatsink: 50W
- Resistor Mounting: Through Hole
- Temperature Coeff. +: 150ppm/°C
- Temperature Coeff. -: 150ppm/°C
- Thermal Resistance: 2.6°C/W
- Tolerance +: 5%
- Tolerance -: 5%
- Voltage Rating V DC: 300V
