Omschrijving
MULTICOMP PRO - 2206PA-10G-739 - Pin Header, Wire-to-Board, 1.27 mm, 1 Rows, 10 Contacts, Through Hole Straight, 2206PA
- Pitch Spacing: 1.27mm
- No. of Contacts: 10Contacts
- Gender: Header
- Product Range: 2206PA Series
- Contact Termination Type: Through Hole
- No. of Rows: 1Rows
- Contact Plating: Gold Plated Contacts
- Contact Material: Copper Alloy
- SVHC: No SVHC (15-Jan-2019)
- Contact Resistance: 20mohm
- Current Rating: 1A
- Flammability Rating: UL94V-0
- Insulation Resistance: 500Mohm
- Operating Temperature Max: 125°C
- Operating Temperature Min: -25°C
- Voltage Rating VAC: 50V
- Withstand Voltage: 500V
