AMP - TE CONNECTIVITY - 280384-2 - Pin Header, Shrouded, Wire-to-Board, 2.54 mm, 2 Rows, 8 Contacts, Through Hole Straight
- Pitch Spacing: 2.54mm
- No. of Contacts: 8Contacts
- Gender: Header
- Product Range: AMPMODU MOD II Series
- Contact Termination Type: Through Hole
- No. of Rows: 2Rows
- Contact Plating: Gold Plated Contacts
- Contact Material: Brass
- SVHC: No SVHC (15-Jan-2019)
- Colour: Black
- Contact Resistance: 15mohm
- Current Rating: 3A
- Flammability Rating: UL94V-0
- Insulation Resistance: 1000Mohm
- Material: Thermoplastic, Glass Filled
- No. of Mating Cycles: 100
- Operating Temperature Max: +80°C
- Operating Temperature Min: -40°C
