Omschrijving
PHOENIX CONTACT - 3044102 - DIN Rail Mount Terminal Block, 2 Ways, 26 AWG, 10 AWG, 6 mm², Screw, 32 A
- No. of Positions: 2Ways
- Wire Size AWG Min: 26AWG
- Wire Size AWG Max: 10AWG
- Conductor Area CSA: 6mm²
- Wire Connection Method: Screw
- Rated Current: 32A
- Rated Voltage: 1kV
- No. of Levels: 1
- Product Range: -
- SVHC: Lead (15-Jan-2019)
- Approvals / Standards: EN 60079, EN 60241
- Colour: Grey
- Connector Mounting: DIN Rail Mount
- Connector Type: Terminal Block, DIN Rail
- External Width: 6.2mm
- Pitch Spacing: 6.2mm
- Voltage Rating VAC: 1000V
- Wire Area Size Max: 4mm²
- Wire Area Size Min: 0.14mm²
- Working Voltage: 800V
