Omschrijving
EPCOS - B43501C5107M000 - Electrolytic Capacitor, Long Life, 100 µF, 450 V, ± 20%, Snap-In, 10000 hours @ 85°C
- Capacitance: 100µF
- Voltage Rating: 450V
- Product Range: B43501 Series
- Lifetime @ Temperature: 10000 hours @ 85°C
- Capacitance Tolerance: ± 20%
- Capacitor Terminals: Quick Connect, Snap-In
- Diameter: 30mm
- Lead Spacing: 10mm
- Operating Temperature Min: -40°C
- Operating Temperature Max: 85°C
- Height: 25mm
- ESR: 1.33ohm
- Automotive Qualification Standard: -
- SVHC: No SVHC (27-Jun-2018)
- AC Ripple Current @ 100Hz: 0.9A
- Capacitance Tolerance ±: ± 20%
- No. of Pins: 2Pins
- Operating Temperature Range: -40°C to +85°C
- Ripple Current Temperature: 85°C
