EPCOS - ACT45B-510-2P-TL003 - Choke, Common Mode, 51 µH, ACT45B Series, 2.8 kohm, 200 mA, 4.5mm x 3.2mm x 3mm
- Rated Current: 200mA
- Inductance: 51µH
- Product Range: ACT45B Series
- Impedance: 2.8kohm
- Common Mode Filter Case: 4.5mm x 3.2mm x 3mm
- Automotive Qualification Standard: -
- SVHC: No SVHC (27-Jun-2018)
- Core Material: Ferrite
- DC Current Max: 200mA
- DC Current Rating: 200mA
- DC Resistance Max: 1ohm
- Inductance Tolerance: -30% to +50%
- Inductor Case Style: SMD
- No. of Pins: 4Pins
- Voltage Rating: 50V
