TE CONNECTIVITY - HSC25082RJ - Resistor, Solder Lug, 82 ohm, HS Series, 250 W, ± 5%, Threaded Stud, 2.5 kV
- Resistance: 82ohm
- Product Range: HS Series
- Power Rating: 250W
- Resistance Tolerance: ± 5%
- Resistor Terminals: Threaded Stud
- Voltage Rating: 2.5kV
- Resistor Element Material: Wirewound
- Temperature Coefficient: ± 50ppm/°C
- SVHC: No SVHC (15-Jan-2019)
- External Depth: 73mm
- External Length / Height: 45mm
- External Width: 109mm
- Fixing Centres LxW: 44.5x57.10
- Fixing Hole Diameter: 5.3mm
- Insulation Resistance: 10000Mohm
- Length: 163mm
- No. of Pins: 2Pins
- Operating Temperature Max: 250°C
- Operating Temperature Min: -25°C
- Operating Temperature Range: -25°C to +250°C
- Resistor Mounting: Panel
