Omschrijving
MULTICOMP PRO - MCDHN-04F-T-V - DIP Switch, Slide Actuator, 4 Circuits, Half Pitch, SPST, 24 VDC, 25 mA, SMD
- No. of Circuits: 4Circuits
- Switch Actuator Style: Flush Slide
- Switch Mounting: SMD
- Contact Configuration: SPST
- Contact Voltage DC Max: 24VDC
- Contact Current DC Max: 25mA
- Product Range: MCDHN Series
- Switch Type: DIP Sealed
- SVHC: No SVHC (15-Jan-2019)
- Contact Resistance: 100mohm
- Dielectric Strength VDC: 300VAC
- External Diameter: 4.5mm
- External Length / Height: 1.42mm
- No. of Electrical Operations: 1000
- No. of Mechanical Operations: 1000
- Operating Force: 500gf
- Operating Temperature Max: 85°C
- Operating Temperature Min: -40°C
- Pitch Spacing: 1.27mm
- Storage Temperature Max: 85°C
- Storage Temperature Min: -40°C
