Omschrijving
COILCRAFT - MSS1278T-224KLD - Power Inductor (SMD), 220 µH, 1.6 A, Shielded, 2.24 A, MSS1278T, 12mm x 12mm x 7.8mm
- Inductance: 220µH
- RMS Current (Irms): 1.6A
- Inductor Construction: Shielded
- Saturation Current (Isat): 2.24A
- Product Range: MSS1278T Series
- Power Inductor Case: 12mm x 12mm x 7.8mm
- DC Resistance Max: 0.3596ohm
- Inductance Tolerance: ± 10%
- SVHC: No SVHC (15-Jan-2019)
- Automotive Qualification Standard: AEC-Q200
- Self Resonant Frequency Min: 3.4MHz
