Omschrijving
BOURNS - SDR0604-2R2ML - Power Inductor (SMD), 2.2 µH, 2.8 A, Unshielded, 5.1 A, SDR0604, 5.8mm x 5.8mm x 4.8mm
- Inductance: 2.2µH
- RMS Current (Irms): 2.8A
- Inductor Construction: Unshielded
- Saturation Current (Isat): 5.1A
- Product Range: SDR0604 Series
- Power Inductor Case: 5.8mm x 5.8mm x 4.8mm
- DC Resistance Max: 0.06ohm
- Inductance Tolerance: ± 20%
- SVHC: No SVHC (07-Jul-2017)
- External Depth: 5.8mm
- External Length / Height: 4.8mm
- External Width: 5.8mm
- No. of Pins: 2Pins
- Operating Temperature Max: 125°C
- Operating Temperature Min: -40°C
- Q Factor: 33
- Q Test Frequency: 7.96MHz
- Resonant Frequency: 79MHz
- Self Resonant Frequency Min: 79MHz
- Test Frequency: 7.96MHz
